Orthopaedic configuration of the PSI Maximus V1 electro-hydraulic table. The brochure specifies different section lengths and a higher height range than the GS model, with extended C-Arm window in normal and reverse orientations and compatibility with modular top traction systems for trauma and orthopaedics.
| Type | Advanced electro-hydraulic surgical table (Orthopaedic configuration) |
|---|---|
| Total length | 2060 mm (Ortho) |
| Head section | 260 mm |
| Back plate section | 420 mm |
| Mid section | 510 mm |
| Hip section | 280 mm (Ortho) |
| Split leg sections | 560 mm (Ortho) |
| Bed width | 530 mm |
| Width with side rails | 580 mm |
| Width with extenders | 730 mm |
| Safe weight bearing (distributed loading) | 400 kg except in top-slide position; 250 kg in top-slide position |
| Height (motorized) | 720 mm min to 1070 mm max (Ortho) |
| Lateral tilt (motorized) | 20° left / 20° right |
| Trendelenburg / reverse (motorized) | 30° / 30° |
| Beach chair (motorized) | 80° / -35° |
| Top slide (motorized) | 300 mm |
| Flex / reflex (motorized, single button) | 240° / 120° |
| Tabletop | Completely radiolucent; optional carbon fiber for 2D & 3D imaging |
